Anderson Greenwood SP/K/P/VPB Instrumentation Manifold Accessories Series
Anderson Greenwood
Product Code: SP/K/P/VPB
Brand: Anderson Greenwood
GET OFFER: info@imtek.com.tr
Description for Anderson Greenwood SP/K/P/VPB Instrumentation Manifold Accessories Series
Seal Pot, Key, Orifice Plate & Vent Purge Blocks A range of accessories to complement the modular mounting system.P - Orifice plate To regulate purge fluid flow, a purge orifice nipple (orifice plate) is available to fit 6mm, 10 mm and 3/8” OD tubing. The orifice size is supplied as requested. Each orifice plate has a tag plate from 1 mm thick 316 SS with a tag number and orifice size information provided. Mesc SPE: 60.95.90/SP - Seal pots[1] For systems requiring an open seal, i.e. high temperature, toxic or corrosive service, the Seal Pot, used with a seal fluid immiscible in the process medium, will provide a barrier for the manifold and instrument. If the instrument is located below the orifice plate, a seal fluid with a higher specific gravity than the process medium is required. If the instrument is located above the orifice plate, a seal fluid with a lower specific gravity should be used. The seal pot has a capacity of approximately 50 cc and is equipped with an integral vent valve. The maximum working pressure is 413 bar at 38°C; maximum working temperature 450°C. Connections are G¼” parallel threaded. Mesc SPE: 60.98.70/510 or 610K - Anti-tamper key A removable T-bar key can be supplied to prevent unauthorized operation of valves. The Anti-tamper bonnet is fitted as standard to all vent and equalize valves on modular mount manifolds. Mesc SPE: 60.98.70.905.1Recommended Products For Anderson Greenwood
