Aoip 988 Blackbody Source For Thermal and Infrared Cameras

Aoip

Product Code: 988
Brand: Aoip



GET OFFER: info@imtek.com.tr

Description for Aoip 988 Blackbody Source For Thermal and Infrared Cameras

The 988 is a low cost Blackbody source introduced to meet customer requirements for a simple, cost effective but high accuracy calibrator for the calibration of thermal imagers and infrared thermometers used at temperatures around ambient.A 70 mm diameter ridged plate is heated or cooled with an internal solid state thermoelectric heat pump. The temperature of the plate can be set from 20°C to 45°C with a resolution of 0.01°C.Evaluation showed the advantages of fitting a stainless steel tube around the plate to give better uniformity and less sensitivity to draughts and ambient temperature effects.Key features:Ambient temperature spherical Blackbody source: 20°C to 45°CEmissivity: 0.97 at ±0.02Controller resolution: 0.01°CTemperature range20°C to 45°CTarget size70 mm diameterStability±0.2°CAccuracy±0.2°CEmissivity0.97 at ±0.02Heating time35 minGeneral specificationsSize230 x 225 x 115 mmWeight4 kgDisplayResolution: 0.01°CPower supply12 V60 Watts
