FMS CA Force Sensor

Force Sensor

DATA SHEET
FMS Tension Control | Force Sensors | CA-Series
CA-Series : Technical data Sensitivity
1.8 mV/ V
Tolerance of sensitivity
< ± 2%
Accuracy class
± 0.5 % (FNom)
Temperature coefficient
± 0.1 % / 10 K
Temperature range
–10 °C to +60 °C (14 F to 140 F)
Input resistance
350 Ω
Power supply
1 to 10 VDC
Overload protection rating
10-times nominal force FNom
Material main body
Stainless steel
Protection class
IP 42
Electrical connection
Male connector M16x0.75, 5-pole
Repeatability error
0.05 %
Measuring range
30 : 1
CA-Series : Order code
CA 203-125 .125 .FL .H14.H16 Options Installation option FL flat with dowel pin for centering
Nominal force rating in N Size: shaft-ø in inches (1.25 in.) or in mm (e.g. M25 = 25 mm)
Series
CA-Series : Options FL
Flat face of force sensor, without shoulder, single screw mount, with dowel pin
PH
Flange mount with 4 screws, pilot hole for centering
H14
Right-angle connector in scope of supply, replaces straight connector
H16
Temperature range up to 120°C (248°F)
H21
Electrical connection with PG gland with 5 m (16.4 ft.) cable, replaces connector
H31
For vacuum applications to 1E-7 hPa , 1E-5 Torr, temperature range up to 120°C (248°F)
H32
Vacuum to 1E-7 hPa , 1E-5 Torr, up to 150°C (302°F), with pg-gland and 5 m (16.4 ft.) cable
H33
Temperature range up to 150°C (302°F), with pg-gland and 5 m (16.4 ft.) cable
CA-Series : Scope of supply l force sensor l straight connector (female) l setting gauge l installation option PH: 4 pcs. DIN912 M6 x 40 l installation option FL: dowel pin
CA-Series : Accessories l prefabricated cable (1 m (3.25 ft.), 5 m (16.4 ft.), 10 m (32.8 ft.), or specify other length), with straight or right-angle female connector
l installation bracket CA203.MB
