Gat ESR 70/16/9 E-slip Ring

Challenge us
Technical Data ROTOFLUX® ESR Type
ESR 70
ESR 110
ESR160
Housing outer diameter Ø (mm)
70
110
160
Number of poles, max.
32
48
80
Rated current, max. (A)
20
40
50
Speed, max. (rpm)
500
250
100
G⅛/G¼
G⅜ / G ½
G1
other housing diameters available
Air connection (“), optional other connection sizes available
Air pressure, max. (bar)
10
Installation position
vertical / horizontal
Protection class
up to IP 65
Technical Data ROTOFLUX® ESW Type
ESW ESW ESW ESW ESW ESW 110 140 200 300 400 525
Free inner diameter Ø, max. (mm)
35
55
100
160
275
395
Housing outer diameter Ø (mm)
110
140
200
300
400
525
Number of poles, max.
80
80
100
150
150
50
Rated current, max. (A)
60
60
60
200
240
60
Speed max. (rpm)
250
250
100
50
50
30
other housing diameters available
Installation position Protection class
vertical / horizontal up to IP 65
Custom products and designs such as devices with larger dimensions, explosion-proof versions or highspeed models are also available.
