Kinetrol 054-030 Spring Closing Unit

Kinetrol Model 05 Spring Unit Specification Spring Torque Start 20.9 Nm / 185 lbf ins
Finish 17.5 Nm / 155 lbf ins For actuated torques see single acting spring return actuator torque data sheets
For reduced spring torques contact Kinetrol Angle of Travel 0° - 90° Materials of Construction
Casing: Pressure die cast aluminium alloy Output Shaft: Steel, zinc plated
Clock Type Spring: Carbon spring steel Finish Epoxy thermoset powder
ATEX Category 2
Weight 1.14 kg / 2.51 lb Operating Temperature -40°C to +80°C (-40°F to +176°F)
Options
ISO Flange / Female drive spring option
High temperature / Low temperature options
ISO adaptor
Available in Blueline paint finish
Non Kinetrol Actuator Application Notes Kinetrol spring units can be used in non Kinetrol actuator applications however the following
must be considered.
A static gasket is provided to seal the base plate mounting face but the user’s shaft must also
be sealed to prevent water ingress into the spring housing.
External stops will need to be used to prevent the spring angle of travel from exceeding 90°.
See Kinetrol installation, operation and maintenance instructions for application example.
