MECHANICS/ELECTRONICSSupply voltage VsDC 10 V ... 30 V 1) 2)Ripple≤ 5 Vpp 3)Power consumption≤ 2.1 W 4)Initialization time≤ 250 msWarm-up time≤ 15 minHousing material
Housing zinc die cast (ZNAL4CU1)
Acrylic glass (PMMA)
Connection typeMale connector, M12, 5-pinIndicationLC display, 2 x LEDWeight200 gEnclosure ratingIP65Protection classIII1) Limit values, reverse-polarity protected, operation in short-circuit protected network: max. 8 A.2) For DT50-xxxx4: VS > 15 V.3) May not fall short of or exceed VS tolerances.4) Without load.PERFORMANCEMeasuring range
200 mm ... 10,000 mm, 90 % remission
200 mm ... 6,500 mm, 18 % remission
200 mm ... 4,000 mm, 6 % remission
TargetNatural objectsResolution1 mmRepeatability≥ 2.5 mm 1) 2) 3)Accuracy± 10 mm 4)Response time20 ms ... 30 ms, 20 ms / 30 ms 3) 5)Output time≥ 4 ms 6)Light sourceLaser, redLaser class2 (IEC 60825-1:2014, EN 60825-1:2014) 7)Typ. light spot size (distance)15 mm x 15 mm (10 m)Additional functionSet moving average: fast/slow, switching mode: distance to object (DtO), teach-in, scaling and inversion of digital output, set hysteresis, teach-in, scaling and inversion of analog output, Multifunctional input: laser off / external teach / deactivated, switch-off display, reset to factory default, lock user interfaceAverage laser service life (at 25 °C)100,000 h1) Equivalent to 1 σ.2) 6 % ... 90 % remission.3) Dependent on the averaging setting: fast/slow.4) 90 % remission.5) Lateral entry of the object into the measuring range.6) Continuous change of distance in measuring range.7) Wavelength: 658 nm; max. output: 180 mW; pulse duration: 5 ns; duty cycle: 1/200.INTERFACESDigital outputNumber1 1)TypePNPMaximum output current IA≤ 100 mAAnalog outputNumber1TypePower outputCurrent4 mA ... 20 mA, ≤ 300 ΩResolution16 bitMultifunctional input (MF)1 x 2) 3)Hysteresis10 mm ... 1,000 mm1) Output Q short-circuit protected.2) Response time ≤ 15ms.3) PNP: HIGH = VS / LOW = ≤ 2.5 V.AMBIENT DATAAmbient temperature operation
–30 °C ... +65 °C
–30 °C ... +80 °C, operation with 2 cooling plates
–30 °C ... +140 °C, operation with 2 cooling plates and protection filter
Ambient storage temperature–40 °C ... +75 °CMax. rel. humidity (not condensing)≤ 95 %Typ. Ambient light immunity40,000 lxVibration resistanceEN 60068-2-6, EN 60068-2-64Shock resistanceEN 60068-2-27CLASSIFICATIONSECl@ss 5.027270801ECl@ss 5.1.427270801ECl@ss 6.027270801ECl@ss 6.227270801ECl@ss 7.027270801ECl@ss 8.027270801ECl@ss 8.127270801ECl@ss 9.027270801ETIM 5.0EC001825ETIM 6.0EC001825UNSPSC 16.090141111613
