FEATURESSystem partSensor and actuatorSensor principleMagneticNumber of N/O contacts1Number of N/C contacts1Number of signaling contacts1Safe switch on distance Sao7 mmSafe switch off distance Sar20 mmActive sensor surfaces1Actuation directions5SAFETY-RELATED PARAMETERSB10d parameter2 x 107 switching cycles (with small load)TypeType 4 (EN ISO 14119)Actuator coding levelLow coding level (EN ISO 14119)Safe state in the event of a faultThe switch has no internal fault detection and is unable to assume a safe state in the event of a fault. Fault detection is performed by the connected safety-related logic unit.FUNCTIONSSafe series connectionNoINTERFACESConnection typeCableLength of cable3 mCable materialPVCELECTRICAL DATAType of outputReed contactsSwitching voltage≤ 30 V DCSwitching current≤ 100 mAMECHANICAL DATADesignRectangularDimensions (W x H x D)26 mm x 36 mm x 13 mmWeight0.2 kgHousing materialGlass-fiber reinforced PPSAMBIENT DATAEnclosure ratingIP67 (IEC 60529)Ambient operating temperature–20 °C ... +60 °CStorage temperature–20 °C ... +60 °CVibration resistance10 Hz ... 55 Hz, 1 mm (EN 60947-5-3)Shock resistance30 g, 11 ms (EN 60947-5-3)CLASSIFICATIONSECl@ss 5.027272402ECl@ss 5.1.427272402ECl@ss 6.027272402ECl@ss 6.227272402ECl@ss 7.027272402ECl@ss 8.027272402ECl@ss 8.127272402ECl@ss 9.027272402ECl@ss 10.027272402ECl@ss 11.027272402ETIM 5.0EC002544ETIM 6.0EC002544ETIM 7.0EC002544UNSPSC 16.090139122205
