Woerner GMZ-E/1/D/0/8/0/0/A Pump Unit

Pump unit GMZ-E
Pump used to supply oil and grease from a barrel directly through a lid-hole or a bunghole.
Technical data:
- Subject to modifications -
Delivery volume per stroke:
Pump element "6":
0,08 cm³/stroke Number of strokes: 1) 22 min-1 Number of pump elements:
1 ... 15 Delivery pressure:
350 bar Lubricant:
Oil:
Viscosity > 180 cP (200 cSt, 26 °E) Grease: Class NLGI 000 ... 2 from class 1 onward follow-up plate
required additionally.
Lubricant: The intended lubricant must be suitable for use with centralized lubrication
equipment.
Pump with bung-hole
Pump with barrel lid
Pipe connection:
6, 8 and 10 mm Temperature range:
-10 ... +40 °C Lower or higher temperatures by request.
Seal material:
NBR (Perbunan) Electrical data:
1 2 3
Motor:
Voltage:
at 50Hz D/Y:
220-240/380-415 V at 60Hz Y:
440-460 V Current:
at 50Hz D/Y:
1,21/0,7 A at 60Hz D/Y:
1,07/0,62 A Rated speed: 1) 1000 min-1 Power rating:
180 W Protection type:
IP55 Insulation class:
F (Other motors upon request) Level monitor: (pressure switch) Switching voltage AC:
at max. 230 VAC at max. 5 A inductive at max. 3 A Switching voltage DC: at max. 125 VDC
at max. 0,4 A inductive at max. 0,05 A Plug connector:
DIN 43650 Protection type:
IP65
4
1 = Elements 2 = Barrel lid 3 = Ring screws (for 200l only)
4 = Grease follow-up plate (for barrel dimensions see 4th page)
Connection diagram:
Switch position shown represents "barrel empty" (pump casing depressurized)
1)
Pump unit GMZ-E 111.460
EUGEN WOERNER
GmbH & Co. KG Postfach 1661 DE-97866 Wertheim Am Eichamt 8 DE-97877 Wertheim
Tel. +49 (0) 9342 803-0 [email protected] Fax.+49 (0) 9342 803-202 www.woerner.de
With standard motor and 50 Hz frequency
Leaflet-No.
Replaces No.
Page 1 of 5
0668.10.07 EN 0668.05.07 EN
