Aron Am3Vmabc3003 Valve
Technical Datasheets / Product Documentations
| Brand |  |
| Category | Valve |
| Product Name | Aron Am3Vmabc3003 Valve |
| Product Code | Am3Vmabc3003 |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
Aron products, including Aron Am3Vmabc3003 Valve, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine Aron parts at competitive prices. Even if Aron Am3Vmabc3003 Valve is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
valves are available with a pressure range of 2 ÷ 320 bar.
Max. operating pressure 320 bar Setting ranges:
spring 1 max. 50 bar spring 2 max. 150 bar spring 3 max. 320 bar Max. flow
40 l/min Hydraulic fluids Mineral oils DIN 51524 Fluid viscosity 10 ÷ 500 mm2/s
Fluid temperature -25°C ÷ 75°C Ambient temperature -25°C ÷ 60°C Max. contamination level
class 10 in accordance with NAS 1638 with filter ß25≥75 Weight AM.3.VM.A/B/P...
1,2 Kg Weight AM.3.VM.AB...
1,3 Kg Weight AM.3.VI.A/B...
2 Kg Weight AM.3.VI.AB...
2,2 Kg
Adjustment is by means of a grub screw or a plastic knob.
AM.3.VM / AM.3.VI...
CMP.10...
Ch. VII page 30 Screws and studs Ch. IV page 21
Three basic versions are available:
- AM3VM on single A or B lines, and on A and B lines, with drainage to T;
- AM3VMP on single P line, with drainage to T;
- AM3VI on single A or B lines, and on A and B lines, with crossed drainage on A or B (see hydraulic symbols).
All versions can accept three types of springs with calibrated ranges as
shown in the specifications.
The cartridge, which is the same for all versions, is the direct acting type
CMP10.
For the minimum permissible setting pressure depending on the spring, see minimum pressure
setting curve.
Ordering code
3
CETOP 3/NG6
**
VM = Maximum pressure
VI = Maximum pressure crossline
**
Adjustment on the lines AM.3.VM Version = A / B / P / AB AM.3.VI Version = A / B / AB
*
Type of adjustment M = Plastic knob C = Grub screw
*
Setting ranges at port A/B/P 1 = max. 50 bar (white spring) 2 = max. 150 bar (yellow spring)
3 = max. 320 bar (green spring)
*
Setting ranges at port B (Omit if the setting is same as that at port A)
1 = max. 50 bar (white spring) 2 = max. 150 bar (yellow spring) 3 = max. 320 bar (green spring)
**
00 = No variant V1 = Viton
3
Serial No.
File: AM3V$003_E
Pressure - Flow rate
AM.3.VM.B
3
P (bar)
Modular valve
AM.3.VM.A
2
AM.3.VM.P
1
AM.3.VM.AB
Q (l/min) Curves n° 1 - 2 - 3 = setting ranges
Minimum setting pressure
AM.3.VI.A
3
AM.3.VI.B
P (bar)
AM
4
Hydraulic symbols
2 1
AM.3.VI.AB Q (l/min)
IV • 9
05/2015/e
