Ascon ALS-3-232 Adapter
Technical Datasheets / Product Documentations
| Brand |  |
| Category | Adapter |
| Product Name | Ascon ALS-3-232 Adapter |
| Product Code | Unspecified |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
Ascon products, including Ascon ALS-3-232 Adapter, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine Ascon parts at competitive prices. Even if Ascon ALS-3-232 Adapter is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
The hardware must be RS-485 compatible.
The line must be made up of a twisted cable with a characteristic impedance
of about 120 W. On the power supply board of the instruments of the "Q" series, there are three jumpers, S1, S2 and S3, with 2 positions that have the
following functions:
Jumper S1 S2 S3
Function of pos. 1 None None None
Function of pos. 2 120 ½ termination Polarization 1 Polarization 1
The standard positions of the switches are indicated in grey.
The S1 pos. 2 termination function is strongly recommended for the two devices located at the two ends of the line, as shown in the following basic diagram:
Host
DEVICE 1
DEVICE 2
DEVICE "n"
Rt
Rt
Signal ground Rg
Rg G/R
Note 1.
G/R
Rg G/R
Rg G/R
The two-wire transception line can be polarized using jumpers S2 and S3.
The polarization must only be carried out on 1 device on the line and both
jumpers must be set to position 2.
G = Generatore R = Ricevitore G/R = Combinazione Generatore Ricevitore Rt
= Resistenza di terminazione: un driver può pilotare 32 ricevitori più 2
resistenze da 120 ½.
Rg = Resistenza da 100 ½.
6.4.1
REFERENCES
Gould Modbus Protocol Reference Guide (PI-MBUS300 Rev. B) APRIL
JBUS Specification
GLOBAL ENG. DOC. EIA STANARD RS -485 GOULD
29
General description
6.4
