Ayvaz DLTKF-75 Universal Type Joint with Tie Rod

Ayvaz

Product Code: DLTKF-75
Brand: Ayvaz



GET OFFER: info@imtek.com.tr

Description for Ayvaz DLTKF-75 Universal Type Joint with Tie Rod

The movements occured in two directions can only be absorbed by using Lateral Expansion Joints. Universal tied expansion joints are made up of two bellows connected each other by an intermediate pipe and a system of tie rods able to withstand the thrust resulted of the internal pressure.Movement AbsorptionThis type of expansion joints are used to absorb lateral movements in all planes. Also, with a specialpositioning of two tie rods at 180 degrees, the expansion joints bocomes able to absorb some lateral and angular deflections at the same time.The amount of lateral deflection depends on the convolution number of the bellows on each side of the expansion joint. This amount can also be increased by changing the length of the intermediate pipe. The tie rods are also effective to prevent possible torsion forces.Advantages of Universal Tied Expansion Joints• Absorption of lateral movements in all planes• Easy to absorb large expansion movements• Minimum application area• Preventing axial inaccuracies increases the system safetyDESIGNStructureBellow Material: Stainless Steel AISI 321 (opt.304,316L,316TI,309)Connection Types: Fixed Flanged and Welded EndFlange Material: Carbon Steel St.37.2 as standard, the material can be customised on requestIntermediate Pipe Material: Carbon Steel St.37.2 as standard, the material can be customised on requestTie Rod Material: Carbon Steel St.37.2 as standard, the material can be customised on requestOperation ConditionsOperating Temperature: -80°C/+600°COperating Pressure: PN 2,5/6/16/25/40/64Nominal Diameters: DN25 (1”) - DN1000 (40”)
