Barksdale D1T, D2T Series Terminal Block Diaphragm Switch
Barksdale
Product Code: D1T, D2T Series
Brand: Barksdale
GET OFFER: info@imtek.com.tr
Description for Barksdale D1T, D2T Series Terminal Block Diaphragm Switch
Barksdale's D1T & D2T Terminal Block Diaphragm Pressure Switches offer superior accuracy in a robust package, making them the ideal solution to your industrial pressure control needs. These switches are ideal for applications requiring water-tight, NEMA 4 housings a covered terminal strip and tamper-proof external adjustment. (Factory set models are also available.) With pressure ranges up to 150 psi, these housed diaphragm pressure switches are suitable for use in either positive pressure or vacuum applications. Single- and dual-circuit models are available. Housed models feature a durable, anodized aluminum enclosure. For applications requiring a highly accurate switch in a durable package, Barksdale's D1T & D2T Terminal Block Diaphragm Pressure Switches are the ideal choice.General Specifications*Accuracy:±0.5% of the adjustable rangeSwitch:Type:Rating:Single pole double throw (SPDT) Snap Action; single circuit10 amps @ 125/250 VAC; 3 amps @ 480 VAC (Class A or H limit switch). Consult sales drawing for ratings of optional limit switches.Wetted Parts:Process Fitting:Diaphragm:Enclosure:304 stainless steel, viton seals17-7 PH stainless steelAnodized aluminumElectrical Connection:Terminal block through 1/2" NPT conduit connectorEnclosure Rating:NEMA 4Pressure Connection:1/4" NPT FemaleApprovals:UL (Optional):CSA (Optional):D1T models may be ordered as UL listed on request. D2T models may be ordered as UL Recognized components on request. File No. E42816All models may be ordered as CSA listed under Class 3231 02, File LR22355 on request.Temperature Range:Operating:Storage:-40° to +165°F (-40° to +74°C)Hermetic Div. 2 models:-4° to +140°F (-20° to +60 °C)-65° to +200°F (-54° to +93°C)Adjustment Instructions:Pressure:Vacuum:Turn adjustment screw counterclockwise to raise actuation point.Turn adjustment screw clockwise to increase setpoint (higher vacuum).Options:- NEMA 4X enclosure- Cleaned for oxygen service- Factory pre-set- Six-pin terminal blockShipping Weight:2.0 lbs. approximate* See product confi gurator for additional options.Wiring CodeLeadCircuit #1Circuit #2PressureVacuumPressureVacuumNormally ClosedBlueRedOrangeYellowCommonPurplePurpleBrownBrownNormally OpenRedBlueYellowOrangeRecommended Products For Barksdale
