Barksdale Series ML1S Bi-Metallic Switch
Barksdale
Product Code: Series ML1S
Brand: Barksdale
GET OFFER: info@imtek.com.tr
Description for Barksdale Series ML1S Bi-Metallic Switch
ML1S Series temperature switches are economic, bi-metallic, factory pre-set temperature switches that complement both our new and traditional temperature switch lines. The ML1S features a one-piece, brass thermowell design, which houses a bi-metallic, SPST snap switch. This one piece, brass housing comes standard with 1/2" process and conduit connections is rated NEMA 4 and IP65 and is UL and CSA recognized. Switching action is SPST, wired normally open or closed and rated for 15 amps @ 125 VAC, 10 amps @ 250 VAC. The one-piece design offers integrity against leaks vs. other welded two-piece designs. For low or high limit alarm, shut-off, or control, the ML1S is ideal for OEM applications when a compact, inexpensive temperature switch is required.General Specifications*Accuracy:See adjacent tableSwitch:SPST-NO or SPST-NCWetted Parts:BrassElectrical Connection:18”, 18 AWG PTFE free leadsElectrical Ratings:15A @ 125 Vac; 10A @ 250 VacEnclosure/HousingNEMA 4Process Connection:1/2" NPTConduit Connection:1/2" NPTProof Pressure:500 psiCycle Life:100,000 cyclesApprovals:CE qualifi edUL and CSA(cURus)Temperature Range:50°F - 300°FProof Temperature:340°FWarranty:1 yearWeight:0.15 lb.* See product confi gurator for additional options.General SpecificationsCatalog NumberSet PointAccuracyDifferential (Fixed)1ML1S-50-I-C50°F (Inc.)±10°F27°F (15°C)ML1S-70-I-C70°F (Inc.)±10°F27°F (15°C)ML1S-75-I-C75°F (Inc.)±10°F27°F (15°C)ML1S-125-I-C125°F (Inc.)±10°F18°F (10°C)ML1S-130-I-C130°F (Inc.)±10°F18°F (10°C)ML1S-165-I-C165°F (Inc.)±10°F18°F (10°C)ML1S-200-I-C200°F (Inc.)±10°F18°F (10°C)ML1S-235-I-C235°F (Inc.)±10°F18°F (10°C)ML1S-275-I-C275°F (Inc.)±10°F27°F (15°C)ML1S-300-I-C300°F (Inc.)±13°F36°F (20°C)ML1S-75-D-C75°F (Dec.)±10°F27°F (15°C)ML1S-130-D-C130°F (Dec.)±10°F18°F (10°C)ML1S-200-D-C200°F (Dec.)±10°F18°F (10°C)1 Differential depends on service conditions and test methodsRecommended Products For Barksdale
