Barksdale Series TXR, TXL Explosion Proof Temperature Switch
Barksdale
Product Code: Series TXR, TXL
Brand: Barksdale
GET OFFER: info@imtek.com.tr
Description for Barksdale Series TXR, TXL Explosion Proof Temperature Switch
Barksdale's TXR & TXL Series Temperature Switches add flexibility to Barksdale's solid reputation for quality & reliability and offer versatility for your temperature switching needs. These thermostats are ideal for freeze protection or temperature control in hazardous applications. The TXR & TXL Series thermostats feature 10 foot stainless steel sensors for remote monitoring and local mount sensors for ambient temperature sensing. The TXR & TXL Series feature limit switches with 22 amps @ 125/250 VAC and 3 amps @ 480 VAC electrical ratings that allow thermostats to be used for higher current, heat tracing applications. The TXR & TXL Series models are all UL listed & CSA approved and ATEX certified for use in hazardous zones within the European Community.General Specifications*Accuracy:±1% of full scaleSwitch:Type:Rating:Single pole double throw (SPDT), prewired snap action22 amp @ 125/250/480 VACElectrical Characteristics:All models incorporate Underwriters’ Laboratories, Inc. and CSA listed single pole double throw snap-action switching elements. Switches may be wired normally open or normally closed.Electrical Connection:3/4" NPT female conduit connection. 3 pole terminal block accepts 16-10 AWG wire.Enclosure Ratings:NEMA 4, 7, 9, & IP65Enclosure/Housing:Anodized aluminum, explosion proof, painted silverBulb and Capillary:Material:Bulb:Capillary Length:System Pressure (max):Fill:316L stainless steel8” (203mm), 5/16” (8mm) dia.10’ (3m), remote mount only300 psi without thermowellSilicone oil-fi lledApprovals:FM, UL fi le E58658, CSA - fi le LR 34556Division 1 and 2, Class I, Group B, C & DClass II, Group E, F & G, Class III.CE 0081, LCIE 07 ATEX 6092XEx II 2 G D, Ex d IIC T6, Ex tD A21 IP6X T80°C-40°C ? Tamb ? +60°C (EX NEPSI, GOST-R)Temperature Range:-40° to 160°F (-40° to 71°C)Ambient Temperature:-40° to 140°F (-40° to 60°C)Adjustment:External adjustment knob. Turn knob clockwise to decrease setpointENI/RFI:to EN 55011Vibration:10 g’s 10-500 Hz, MIL-STD 202FShock:50 g’s, 10 mS, MIL-STD 901CStandard Options:-R (suffi x):Double pole single throw (DPST) relay 22 amp @ 120/240/277 VAC. Contacts close on falling temperature. Relay Coil: 120 VAC, 4VA. Example: TXR-L2S-10R-Q10Weight:3.8 lb (1.7 kg)* See Product Confi gurator for additional options.General SpecificationsMedia Temperature LimitsAdjustable RangeDifferential (approximate)Sensing LocationCatalog Number-40° to 420°F(-40° to 215°C)25° to 325°F(-4° to 163°C)10°F(5.6°C)Line Sensing T-statTXR-L2S-10-Q10-40° to 160°F(-40° to 71°C)15° to 140°F(-9° to 60°C)10°F(5.6°C)Ambient Sensing T-statTXL-L1S-Q10Recommended Products For Barksdale
