Barksdale T9692X Compact Explosion Proof Temperature Switch
Barksdale
Product Code: T9692X
Brand: Barksdale
GET OFFER: info@imtek.com.tr
Description for Barksdale T9692X Compact Explosion Proof Temperature Switch
Barksdale's explosion proof compact temperature switches are ideal for hazardous location and heavy industrial applications where space is a premium and the customer needs a compact and rugged design, UL and CSA Class 1 Div 1, IECEx and ATEX approvals, and easy set point adjustment. Paired with the 9681X and 9692X pressure switches, Barksdale offers a complete and reliable solution for your mission critical applications.General Specifications*Accuracy:± 3% of full scaleTypical Life:1 million cyclesSwitch:SPDT, snap action, Class EE, simulated DPDT (optional)Electrical Ratings:11 amps @ 125/250 VAC5 amps @ 30 VDC (EE class)Materials:Bulb, Capillary & Armor:Enclosure:Local Mount Element:316 stainless steel316 stainless steel300 series stainless steelElectrical Connection:1/2 inch NPT male conduit connection 18 AWG, 18” (300 mm) free leadsEnclosure Ratings:NEMA 4X, 7 & 9Approvals:ATEX/IECEx:UL:CSA:CE 0081 LCIE 08 ATEX 6074XII 2 G Ex d IIC T6 Gb IECEx LCIE 17.0001X, -40°C ? Tamb ? 60°CListed 366S, Class: I, Groups: A, B, C, D,-25°C ? Tamb ? 60°CClass: I, Groups: B, C, D-40°C ? Tamb ? 60°CAmbient Operating Temperature:CSA & ATEX:UL:-40°F to 140°F (-40°C to 60°C)-13°F to 140°F (-25°C to 60°C)EMI/RFI:EN55011Vibration:10g’s 10-500 Hx, MIL-STD 202°FShock:50g’s, 11 ms, MIL-S-901CAdjustment:Internal locking adjustment wheel, 1/16 hex set screwWeight:3 lbs. maximum* See Product Confi gurator for additional options.Wiring CodeLeadCircuit #1Circuit #2Normally ClosedBlueOrangeCommonPurpleBrownNormally OpenRedYellowGroundGreenRecommended Products For Barksdale
