Barksdale UNS-2000 Series (Formerly Series BLS 800) Multi Level Switch

Barksdale

Product Code: UNS-2000 Series (Formerly Series BLS 800)
Brand: Barksdale



GET OFFER: info@imtek.com.tr

Description for Barksdale UNS-2000 Series (Formerly Series BLS 800) Multi Level Switch

Barksdale's Series UNS 2000 Level Switches offer a level control solution that is fully customizable to the exact needs of your application. This series of Level Switches can be configured with up to six floats, each with its own individual switch point. A variety of mounting options and materials are available, ensuring compatibility with your vessel. Floats are available in stainless steel and Buna-N, ensuring a broad range of media compatibility. Alternative materials may be available upon request. Switches may be configured either as one common circuit (Group 1 or 2) or as independent circuits (Group 3 or 4), with SPST or SPDT reed switches. For applications requiring multiple setpoints, an integral temperature switch (optional) and high pressures up to 580 psi, the UNS-2000 is the level switch to choose.General Specifications*Max. Operating Pressure:580 PSI (40 bar), depends on mounting element and floatMinimum Specific Gravity:NBR (BUNA):S.S:0.6 g/cm30.78 g/cm3Mounting Position:Vertical, ±30°, through top or bottomProtection Class:IP65 for ST-, KL- and PG-designIP67, IP68 on requestIP54 for K-designOperating Temperature:+14 °F to +221 °F (-10 °C to +105 °C), PVC-cableSpecial Design Options:(On Request)DR - Damping TubeHT - High Temperature Application -(-40 °C up to +150 °C) F- Silicone CableU - Mounting location through bottomPT100 - PT100-ElementTP - Temperature switchV V - Vertical AdjustmentEXi - ATEX-approval EEx iaContact Mode:NO or NC are defi ned on the basis of an empty tank and for installation through the topWeight:Depends on length and designMax. SwitchpointsKL6C AL Terminal BoxKL12C AL Terminal BoxST1 DIN ConnectorST2 DIN ConnectorPG Cable glandConnect Group 156256Connect Group 224124Connect Group 334134Connect Group 423123CombinationsMaterialMountingElectrical ConnectionFloatStainless Steel (VA)T1-1/4 NPTT2 NPTFLASDIN Connector (ST1 & ST2)Terminal box (KL6Cor KL12C)Cable gland (PG)PVC Cable (K)StainlessSteel (VA52)1/2 NPTCable gland (PG)PVC Cable (K)Brass (MS)T1-1/4 NPTT2 NPTDIN Connector (ST1 & ST2)Terminal box (KL6Cor KL12C)Cable gland (PG)PVC Cable (K)NBR(Buna-N)(BN30)1/2 NPTCable gland (PG)PVC Cable (K)
