Each assembly must be terminated at the right hand end with an EL9011 bus end cap.
Technical dataEL9011Technologybus end coverCurrent load–Power LED–Defect LED–Renewed infeed–Current consumption E-bus–Integrated fine-wire fuse–Diagnostics in the process image–Reported to E-bus–PE contact–Shield connection–Connection facility to additional power contact–Bit width in the process image0Electrical connection to DIN rail–Housing width5 mmSide by side mounting on
EtherCAT Terminals with
power contactyesSide by side mounting on
EtherCAT Terminals without
power contactyesSpecial featurescover for E-bus contactsWeightapprox. 10 gOperating/storage temperature-25…+60 °C/-40…+85 °CApprovals/markingsCE, UL, ATEXEx markingII 3 G Ex nA IIC T4 Gc
