BECKHOFF EL9080 Separation terminal
Technical Datasheets / Product Documentations
- No technical documentation is available for this product at the moment. Contact us for more information.
| Brand |  |
| Category | Terminal |
| Product Name | BECKHOFF EL9080 Separation terminal |
| Product Code | EL9080 |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
BECKHOFF products, including BECKHOFF EL9080 Separation terminal, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine BECKHOFF parts at competitive prices. Even if BECKHOFF EL9080 Separation terminal is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
The EL9080 is used to identify potential groups (e.g. 230 V AC/24 V DC). It is inserted between two potential groups, and indicates the separation through an orange coloured cover.
| Technical data | EL9080 |
|---|---|
| Technology | separation terminal |
| Current load | – |
| Power LED | – |
| Defect LED | – |
| Renewed infeed | – |
| Current consumption E-bus | – |
| Nominal voltage | – |
| Integrated fine-wire fuse | – |
| Electrical isolation | 500 V (E-bus/field potential) |
| Diagnostics in the process image | – |
| Reported to E-bus | – |
| PE contact | – |
| Shield connection | – |
| Connection facility to additional power contact | – |
| Bit width in the process image | 0 |
| Electrical connection to DIN rail | – |
| Housing width | 12 mm |
| Side by side mounting on EtherCAT Terminals with power contact | yes |
| Side by side mounting on EtherCAT Terminals without power contact | yes |
| Special features | placeholder terminal with E-bus transmission |
| Weight | approx. 50 g |
| Operating/storage temperature | -25…+60 °C/-40…+85 °C |
| Approvals/markings | CE, UL, ATEX |
| Ex marking | II 3 G Ex nA IIC T4 Gc |
