BECKHOFF KL1202| 2-Channel Digital Input Terminal
Technical Datasheets / Product Documentations
- No technical documentation is available for this product at the moment. Contact us for more information.
| Brand |  |
| Category | Terminal |
| Product Name | BECKHOFF KL1202| 2-Channel Digital Input Terminal |
| Product Code | KL1202 |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
BECKHOFF products, including BECKHOFF KL1202| 2-Channel Digital Input Terminal, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine BECKHOFF parts at competitive prices. Even if BECKHOFF KL1202| 2-Channel Digital Input Terminal is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
The EL1202 digital input terminal acquires the binary control signals from the process level and transmits them, in an electrically isolated form, to the higher-level automation unit. It is suitable for particularly fast signals due to its very low input delay. The EtherCAT Terminal can support distributed clocks, i.e. the input data can be monitored synchronously with other data that are also linked to distributed clock terminals. To this end, the user has to switch to terminal version EL1202-0100 (see documentation). The DC accuracy across the system is << 1 µs. For this, the user has to switch the terminal to the EL1202-0100 version (see documentation). The EL1202 contains two channels whose signal state is indicated via LEDs.
| Technical data | EL1202 | ES1202 |
|---|---|
| Connection technology | 4-wire |
| Specification | similar to EN 61131-2, type 3, “0”: -3…5 V DC, “1”: 11…30 V DC, typ. 3 mA input current |
| Number of inputs | 2 |
| Nominal voltage | 24 V DC (-15 %/+20 %) |
| “0“ signal voltage | -3…+5 V (similar to EN 61131-2, type 3) |
| “1“ signal voltage | 11…30 V (similar to EN 61131-2, type 3) |
| Input current | typ. 3 mA (similar to EN 61131-2, type 3) |
| Input filter | typ. < 1 µs |
| Precision of timestamp in the terminal | 10 ns (+ input delay) |
| Distributed clock precision | << 1 µs |
| Input delay TON/TOFF | < 1 µs |
| Distributed clocks | can be activated, see documentation |
| Current consumption power contacts | typ. 6 mA + load |
| Current consumption E-bus | typ. 110 mA |
| Electrical isolation | 500 V (E-bus/field potential) |
| Bit width in the process image | 2 inputs |
| Configuration | no address or configuration setting |
| Special features | DC can be activated, see documentation |
| Weight | approx. 55 g |
| Operating/storage temperature | 0…+55 °C/-25…+85 °C |
| Relative humidity | 95 %, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. class/installation pos. | IP 20/variable |
| Pluggable wiring | for all ESxxxx terminals |
| Approvals | CE, UL, Ex |
