BECKHOFF KL2652 | 2-Channel Relay Output Terminal
Technical Datasheets / Product Documentations
- No technical documentation is available for this product at the moment. Contact us for more information.
| Brand |  |
| Category | Terminal |
| Product Name | BECKHOFF KL2652 | 2-Channel Relay Output Terminal |
| Product Code | KL2652 |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
BECKHOFF products, including BECKHOFF KL2652 | 2-Channel Relay Output Terminal, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine BECKHOFF parts at competitive prices. Even if BECKHOFF KL2652 | 2-Channel Relay Output Terminal is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
The KL2652 output terminal has two relays, each featuring a change-over contact. The relay contact can be used universally for switching devices requiring mains power up to 230 V AC or 300 V DC. The KL2652 Bus Terminal is equipped with potential-free contacts. The signal state of the Bus Terminal is indicated via LEDs.
| Technical data | KL2652 | KS2652 |
|---|---|
| Number of outputs | 2 x change-over |
| Nominal voltage | 230 V AC (max. switching voltage 250 V AC/300 V DC) |
| Switching voltage max. | 250 V AC, 300 V DC |
| Load type | ohmic, inductive, lamp load |
| Max. output current | 5 A per channel |
| Switching current | max. 1 A AC/1 A DC at 40 V DC; max. 0.15 A at 300 V DC (UL: max. 230 V AC, 1 A) |
| Switching current max. | 1 A AC/1 A DC at 40 V DC; 0.15 A at 300 V DC (UL: max. 230 V AC, 1 A) |
| Minimum permitted load | 100 mA (12 V DC) |
| Lamp test, electronic ballast | max. 6 A starting current |
| Electrical isolation | 1.5 kV (K-bus/field potential); 2.5 kV rated surge voltage, overvoltage category III |
| Current consumption power contacts | – |
| Current consumption K-bus | typ. 90 mA |
| Bit width in the process image | 2 outputs |
| Switching frequency max. | 6/min. (at rated load) |
| Operating cycles mech. (min.) | 5 x 106 |
| Operating cycles electr. (min.) | 1 x 106 (1 A/250 V AC) |
| Configuration | no address or configuration setting |
| Special features | reverse switching realisable |
| Weight | approx. 55 g |
| Operating/storage temperature | 0…+55 °C/-25…+85 °C |
| Relative humidity | 95 %, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. class/installation pos. | IP 20/variable |
| Pluggable wiring | for all KSxxxx Bus Terminals |
| Approvals | CE, UL |
