BECKHOFF KL6011 Serial Interface TTY, 20 mA Current Loop
Technical Datasheets / Product Documentations
- No technical documentation is available for this product at the moment. Contact us for more information.
| Brand |  |
| Category | Others |
| Product Name | BECKHOFF KL6011 Serial Interface TTY, 20 mA Current Loop |
| Product Code | KL6011 |
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Product Description
BECKHOFF products, including BECKHOFF KL6011 Serial Interface TTY, 20 mA Current Loop, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. As an authorized trading partner, Imtek Engineering offers genuine BECKHOFF parts at competitive prices. Even if BECKHOFF KL6011 Serial Interface TTY, 20 mA Current Loop is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.
The KL6011 serial interface allows devices with a 20 mA current interface to be connected. The interface operates passively. The device connected to the KL6011 terminal communicates with the automation device via the Bus Coupler. The active communication channel operates independently of the higher-level bus system in full duplex mode at up to 19,200 baud. The current interface (TTY) guarantees high immunity to interference through electrically isolated signals with injected current.
| Technical data | KL6011 | KS6011 |
|---|---|
| Technology | TTY |
| Data transfer channels | 2 (1/1), TxD and RxD, full duplex |
| Data transfer rates | 1,200…19,200 baud; default: 9,600 baud, 8 data bits, no parity and one stop bit |
| Bit transfer | 2 x 20 mA |
| Load | < 500 Ω |
| Line impedance | – |
| Cable length | max. 1,000 m twisted pair |
| Power supply | via the K-bus |
| Current consumpt. K-bus | typ. 55 mA |
| Current consumption power contacts | – (no power contacts) |
| Electrical isolation | 500 V (K-bus/signal voltage) |
| Data buffer | 128 bytes receive buffer, 16 bytes transmit buffer |
| Bit width in the process image | input/output: 3 x 8 bit user data, 1 x 8 bit control/status (up to 5 x 8 bit user data are possible) |
| Configuration | no address setting, configuration via Bus Coupler or controller |
| Special features | 2 x 20 mA bit transfer |
| Weight | approx. 60 g |
| Operating/storage temperature | 0…+55 °C/-25…+85 °C |
| Relative humidity | 95 %, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. class/installation pos. | IP 20/variable |
| Pluggable wiring | for all KSxxxx Bus Terminals |
| Approvals | CE, UL, Ex |
| Special terminals | |
|---|---|
| KL6011-0020 | standard format 5 bytes of user data |
