Bimba H-1 Single Acting Air Clamp

Bimba

Product Code: H-1
Brand: Bimba



GET OFFER: info@imtek.com.tr

Description for Bimba H-1 Single Acting Air Clamp

Bimba's single acting air clamps provide gripping power on the out stroke and spring retraction. They are ideal for use in drill fixtures, bending, forming, crimping, and pressing operations. Because 3-way valves may be used, hook-ups are quick and easy.  Some air clamps are supplied with an adjustable front head so the stroke may be adjusted by as much as one inch.Pressure:  Air to 150 PSITemperature:  -40° to +125°Seal Material:  Custom molded one piece neoprene cupsBody:  Aluminum on adj. models, cast iron on H-12/H-283, cast aluminum on othersRod:  Nitrotec plated steel on 1 inch bore models, ground and polished on all othersFiltration:  40µ minimumEngineering SpecificationsPressure Rating: 150 PSI AirTemperature Range: -40° F (-40° C) to 250° F (120° C)Filtration: 40? minimumLubrication: Petroleum base oilMaterials:Rod: Nitrotec plated steel on 1" bore models, ground &polished on all othersBody & Cover: Aluminum on adjustable models, castaluminum on all other models (Cast iron on H-12 andH-283)Seals: Custom molded one-piece neoprene cups
