Brinkmann KC35 Miniature Centrifugal Pump
Product Code:KC35
Description
KC21, 31, 35, 45, KC60 -Open/peripheral impellers
Miniature Centrifugal Pumps series KC are suitable for pumping thinbodied fluids. They operate according to the bypass duct principle, with self-priming function following initial priming.
Applications
Types of fluid
Kinematic viscosity
12 mm²/s (12 cSt)Pumping temperature
0 – 80°CSuction height
2 m without foot-located valve6 m with foot-located valveConstructionCoverBronzeImpellersBrassShaftCr-steelGasketNoise levelKC3557 dBAKC4560 dBAKC21 – 3163 dBAKC6065 dBA
Technical Specifications
KC21, 31, 35, 45, KC60 -Open/peripheral impellers
Miniature Centrifugal Pumps series KC are suitable for pumping thinbodied fluids. They operate according to the bypass duct principle, with self-priming function following initial priming.
Applications
Types of fluid
- water
- coolants
- fuel oil
Kinematic viscosity
- 12 mm²/s (12 cSt)
Pumping temperature
- 0 – 80°C
Suction height
- 2 m without foot-located valve
- 6 m with foot-located valve
| Construction | |
| Cover | Bronze |
| Impellers | Brass |
| Shaft | Cr-steel |
| Gasket | |
| Noise level | |
| KC35 | 57 dBA |
| KC45 | 60 dBA |
| KC21 – 31 | 63 dBA |
| KC60 | 65 dBA |
