Sludge submersible pumps
SAL901 ... 904

Axial / semi-open impellers

Sludge submersible pumps
with patented "BRINKMANN suction ventilation system" are ideal for pumping cooling lubricants containing high levels of air (emulsions or cooling and cutting oils), such as occur with high machining through turning, milling or grinding.
The suction submersible pumps reach a stable delivery state as soon as the liquid level covers the suction opening.
SAL series with interchangeable flange optionally for vertical or horizontal pipe connection with pressure gauge connection G ¼ .

SAL901 ... 904Technical drawingCharacteristicsField of application

Media
Cooling emulsions cooling and cutting oilsKinematic viscosity... 45 mm² / s (45 cSt)Delivery temperature0 ... 80 ° Cexecution

Pump bodyCast ironcoverCast ironAxial impellerCast steelRadial impellerCast steelwavestoleTechnical specifications

TypeFlow
at
headup
measureDiving
depthoverall
weight Leist-
clothesChip
voltage
3 ~frequency
frequencyelectricityrotary
speedl / min / mH mmh mmkgkWVHzA1 / minSAL901 / 220    600/1250322062.03.3220-2405011.62930320      32066.0 380-415506.72930450      45069.0     570      57073.03.8460606.43520770      77086.0     1000      100092.0     1120      112097.0     SAL902 / 290    600/2157429099.06.0380-4155011.22950390      390103.0     520      520106.06.94606010.73550640      640109.0
