Brinkmann TGL501 / 150 Slurp submersible pump

Brinkmann

Product Code: TGL501 / 150
Brand: Brinkmann



GET OFFER: info@imtek.com.tr

Description for Brinkmann TGL501 / 150 Slurp submersible pump

Quick Suctioning Immersion Pumpsseries TGL/SGL equipped with the patented "BRINKMANN`s Suction De-aeration System" are excellently suited to pumping extremely air entrained fluids (grinding oils) as they occur in high-speed grinding.The quick suctioning immersion pumps reach stable working conditions as soon as the liquid level reaches the suction inlet.The SGL serie offers a (SAE) flange with pressure gauge connection port.The flange can be rotated for either horizontal or vertical pipe connections.TGL/SGL501...503Engineering drawingPump characteristicApplicationsTypes of fluidcoolantscooling/cutting oilsgrinding oilsKinematic viscosity...45 mm²/s (45 cSt)Pumping temperature0...80° CConstructionPump bodycast ironCovercast ironImpeller axialcast steelImpeller radialcast steelShaftsteelTechnical dataTypeVol. del.at manom.del. headHeightDepthof im-mersionWeight PowerVoltage3 ~Fre-quen-cyCurrentSpeedl/min /mH mmh mmkgkWVHzA1/minTGL501/150    250/629115017.01.1220-240504.332850230      23018.5 380-415502.502850300      30019.5     380      38020.51.27460602.43440470      47021.5     580      58022.5     SGL501/150    250/636115023.51.1220-240504.332850230      23024.5 380-415502.502850300      30025.5     380      38027.01.27460602.43440470      47028.0     580      58030.0     780      78036.0     930      93038.0     SGL502/220    250/1543921540.02.2220-240507.82890300      29541.0 380-415504.52890370      36542.0     450      445
