Celem C700T Conduction Cooled Capacitor

Celem

Product Code: C700T
Brand: Celem



GET OFFER: info@imtek.com.tr

Description for Celem C700T Conduction Cooled Capacitor

The C700T is a High Voltage version of the most popular C500T, this new series comes in capacitance values from 5uF to 85uF.  C700T has the exact height of C500T to allow combination of C700T and C500T capacitors between the same plates or increase capacitance or voltage on existing systems. The capacitors offer voltages up to 1000Vrms and currents up to 1400Arms. Starting on mid April 2013, Celem supplies a new version of C700T with 5 mounting holes on each electrode. The new version of C700T is fully compatible with the previous version. Standard applications: Induction heating, resonant circuits, medical imaging, heat treatment, EV (electric vehicle) charging, IPT, high frequency inverters, plasma applications, wireless power transfer, etc. Features: Polypropylene Conduction-cooled capacitor High Power Self-Healing capacitor Low ESR Low losses UL94-V0 available upon request.   The C700T capacitor complies with RoHS.Specifications TYPE C700T Dimensions ( D X H ) mm Ø128 x 71.5 Weight kg 1.9 2 1.9 2 2.1 2.2 Capacitance (±10%) ?F 5 9 14 19 27 46 85 Sinusoidal Voltage Vrms 1000 900 850 800 700 600 500 Peak Voltage Vpeak 1410 1270 1200 1130 990 850 710 Max. Current Arms 800 900 1000 1100 1200 1400 Max. Power kVAr 700 Freq Range @ Full Power kHz 22-29 15.3-20 11-16.2 9.2-12 8.4-10.2 6.7-7.1 5.2-5.2 Stray Inductance nH < 10
