Celem CSM 150 Conduction Cooled Capacitor

Celem

Product Code: CSM 150
Brand: Celem



GET OFFER: info@imtek.com.tr

Description for Celem CSM 150 Conduction Cooled Capacitor

The 150kVAr rated CSM 150 and its newly developed versions (CSM 150/200 and CSM 150/300) are Celem’s most popular capacitors.  The unique patented structure enables rapid mounting and dismounting of the capacitor. As a result, many customers use the CSM 150 as a building block for parallel and serial capacitor combinations. Celem AS 150/3 and the AS 150/5 assembly systems are ideal for creating CSM 150 assemblies. Please note that the newer CSM 150/200 and CSM 150/300 have the same physical dimensions as the CSM 150 but are rated for higher voltage and higher current and can carry up to 200 and 300kVAr respectively. Standard applications: Induction heating, heat treatment, plasma applications, resonant circuits, medical imaging, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters,etc. Features: Polypropylene Conduction-cooled capacitor High Power Self-Healing capacitor Low ESR Low losses UL94-V0 available upon request.   The CSM 150 capacitor complies with RoHS.Specifications Dimensions (LxWxH) mm 68 x 30.2 x 30 Weight kg 0.3 Capacitance (±10%) ?F 0.05 0.1 0.17 0.33 0.5 0.66 1.33 2.4 Sinusoidal Voltage Vrms 1000 700 600 500 400 Peak Voltage Vpeak 1410 990 850 710 570 Max. Current Arms 200 250 300 400 Max. Power kVAr 150 Freq Range @ Full Power kHz 477-849 239-424 287-390 148-201 97-133 100-145 72-72 62-71 Stray Inductance nH < 3
