Celem CSP 180 Conduction Cooled Capacitor
Celem
Product Code: CSP 180
Brand: Celem
GET OFFER: info@imtek.com.tr
Description for Celem CSP 180 Conduction Cooled Capacitor
The 180 kVAr CSP 180 polypropylene capacitor can be mounted either between two parallel plates or, with the use of special adaptors (shoes), on top of 2 bus bars. A CSP 180 to be mounted between plates can be replaced by the 300kVAr CSP 180/300, which has similar dimensions and a lower price. A CSP 180 to be mounted on top of two bus bars can be replaced by the 300kVAr CSM 300N, which has similar dimensions and a lower price. Standard applications: Induction heating, resonant circuits, medical imaging, heat treatment, plasma applications, wireless power transfer, EV (electric vehicle) charging, IPT, high frequency inverters, etc. Features: Polypropylene Conduction-cooled capacitor High Power Self-Healing capacitor Low ESR Low losses UL94-V0 available upon request. The CSP 180 capacitor complies with RoHS. Specifications TYPE CSP 180 Dimensions (LxWxH) mm 75 x 50 x 30.2 Weight kg 0.5 Capacitance (±10%) ?F 0.18 0.24 0.33 0.66 1.3 2.4 5 Sinusoidal Voltage Vrms 700 600 500 400 Peak Voltage Vpeak 990 850 710 570 Max. Current Arms 350 400 340 450 500 600 Max. Power kVAr 180 Freq Range @ Full Power kHz 325-602 244-550 177-280 89-271 61-170 48-92 36-64 Stray Inductance nH < 5Recommended Products For Celem
