BECKHOFF KS1032 2-channel digital input terminal 48 VDC

Technical Documentation

技术数据表 / 产品文档

  • 目前暂无此产品的技术文档。如需更多信息，请与我们联系。
WhatsApp
品牌
BECKHOFF logo - Official brand
类别端子
产品名称BECKHOFF KS1032 2-channel digital input terminal 48 VDC
产品编号KS1032
Visa – Secure credit card payment acceptedMastercard – Secure credit card payment acceptedAmerican Express – Secure credit card payment acceptedDiners Club – Secure credit card payment acceptedDiscover – Secure credit card payment accepted

欢迎联系我们！我们会在 24 个工作小时内（不含周末及节假日）确认库存状态和预计交期。

产品描述

BECKHOFF的产品（包括BECKHOFF KS1032 2-channel digital input terminal 48 VDC）通过平行进口渠道采购，并快速可靠地交付给United States的客户。Imtek Engineering以具有竞争力的价格提供正品BECKHOFF零部件。即使BECKHOFF KS1032 2-channel digital input terminal 48 VDC未在我们的网站上列出，您也可以随时申请报价——我们的团队将迅速响应并为您提供专属报价。

KL1032 | 2-channel digital input terminal 48 V DC

The KL1032 digital input terminal acquires the binary control signals from the process level and transmits them, in an electrically isolated form, to the higher-level automation unit. The Bus Terminal contains two channels that indicate their signal state by means of light emitting diodes. Further voltage values are available on request.

Technical dataKL1032 | KS1032
Connection technology4-wire
Number of inputs2
Nominal voltage48 V DC (-15 %/+20 %)
“0“ signal voltage-6…+34 V
“1“ signal voltage34…60 V
Input filtertyp. 3.0 ms
Input currenttyp. 3.5 mA
Current consumpt. K-bustyp. 3 mA
Electrical isolation500 V (K-bus/field potential)
Bit width in the process image2 inputs
Configurationno address or configuration setting
Special featuresfurther voltage values on request
Weightapprox. 50 g
Operating/storage temperature0…+55 °C/-25…+85 °C
Relative humidity95 %, no condensation
Vibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4
Protect. class/installation pos.IP 20/variable
Pluggable wiringfor all KSxxxx Bus Terminals
ApprovalsCE, UL, Ex, GL
