  4. BECKHOFF KS2692 Cycle monitoring terminal (watchdog)

BECKHOFF KS2692 Cycle monitoring terminal (watchdog)

Technical Documentation

技术数据表 / 产品文档

  • 目前暂无此产品的技术文档。如需更多信息，请与我们联系。
WhatsApp
品牌
BECKHOFF logo - Official brand
类别端子
产品名称BECKHOFF KS2692 Cycle monitoring terminal (watchdog)
产品编号KS2692
Visa – Secure credit card payment acceptedMastercard – Secure credit card payment acceptedAmerican Express – Secure credit card payment acceptedDiners Club – Secure credit card payment acceptedDiscover – Secure credit card payment accepted

欢迎联系我们！我们会在 24 个工作小时内（不含周末及节假日）确认库存状态和预计交期。

产品描述

BECKHOFF的产品（包括BECKHOFF KS2692 Cycle monitoring terminal (watchdog)）通过平行进口渠道采购，并快速可靠地交付给United States的客户。Imtek Engineering以具有竞争力的价格提供正品BECKHOFF零部件。即使BECKHOFF KS2692 Cycle monitoring terminal (watchdog)未在我们的网站上列出，您也可以随时申请报价——我们的团队将迅速响应并为您提供专属报价。

KL2692 | Cycle monitoring terminal (watchdog)

The KL2692 Bus Terminal monitors a bit that is toggled by the controller during each cycle. If the toggle signal fails, the controller switches off two potential-free relay circuits in order to prevent damage to the machine. Failure of the toggle signal may be caused by the PLC cycle stopping, by a fault in the bus cable or connector, or by a fault in a bus device. The cycle monitoring time can be parameterised. The Bus Terminal has an enable input that enables the relay to be switched on if a correct toggle signal is detected.

Technical dataKL2692 | KS2692
Connection technology2-wire
Number of outputs2 potential-free relay outputs (normally-open contacts)
Number of inputs2 digital 24 V inputs
Rated load voltage30 V DC
Max. output current3 A per channel
Ohmic switching current5 A AC/DC per channel
Inductive switching current2 A AC/DC per channel
Minimum permitted load10 mA at 5 V DC
Electrical isolation500 V (K-bus/field potential)
Current consumption power contacts–
Current consumption K-bustyp. 165 mA
Bit width in the process image2 x 8 bit data, 1 x 8 bit control/data
Operating cycles mech. (min.)2 x 107
Operating cycles electr. (min.)1 x 105 (5 A/30 V DC)
Configurationvia the Bus Coupler or the controller
Weightapprox. 60 g
Operating/storage temperature0…+55 °C/-25…+85 °C
Relative humidity95 %, no condensation
Vibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4
Protect. class/installation pos.IP 20/variable
Pluggable wiringfor all KSxxxx Bus Terminals
ApprovalsCE, UL
Product announcementKL2692: available
KS2692: estimated market release on request
