Coax FCF 100 2/2 Way Externally Controlled Coaxial Valve

Coax

Product Code: FCF 100
Brand: Coax



GET OFFER: info@imtek.com.tr

Description for Coax FCF 100 2/2 Way Externally Controlled Coaxial Valve

PortsFCF flanges ANSI 150 / 600FunctionNCPressure Range0-240 / 0-600 psicv Value248.5 GPMMediaemulsions, oils - neutral gasesFlow DirectionA ? B as markedSwitching Cycles40 1/minSwitching Time [ms]opening 450-3000 closing 300-3000Media Temperature [°F]direct mounted pilot valve 140Ambient Temp. [°F]direct mounted pilot valve 122Weight [kg]FCF 34,0Additional Equipmentsensor / manometer connection NPT 1/4Nominal VoltageUN DC 24V, UN AC 230V 50 HzPower ConsumptionDC 4,8 W, AC pick up 11,0 VA holding 8,5 VAProtectionIP 65 (P54) acc. DIN 40 050Energized Duty RatingED 100%
