United States• One module for all fields of application
• Illumination 180°
• High flexibility due to junction box
• Low installation depth
Explosion protection
Dimensions
II 2G Ex db eb IIC Gb I M2 Ex db eb I Mb
CML 17 ATEX 1106 U
Marking IECEx
Ex db eb IIC Gb Ex db eb I Mb
Certification
IECEx CML 17.0046 U
68
72.2
Certification
99
38
∅19
Marking ATEX
The ComEx flex lamp module indicates command modes by means of a light signal
lighting up or going out. It is suitable for use in almost all explosive areas in which
a visual indication of a machine’s functional status is required. The lamp module
can be combined with various lamp module actuating elements. A junction box
is available to facilitate a safe and convenient installation of the module
into a control panel. The conductors are connected by means of terminals
on the back of the module which have an increased safety level. The lamp
module actuating elements can be fitted easily, without the use of tools,
which ensures conformance to the high IP degree of protection.
Other approvals and certificates, see www.bartec.de Ambient temperature
-55 °C to +60 °C
Technical data Technical data
determined by actuating element and control station enclosure, min. IP 66,
terminals IP 20 (IEC 60529).
Rated insulation voltage
300 V
Rated operating voltage
AC 12 V to 250 V
DC 12 V to 60 V AC/DC 12 V to 24 V
Ordering information Wiring diagram
(Ta < +50 °C) (Ta < +50 °C) (Ta < +60 °C)
Colour LED
Code no.
Colour actuator
Code no.
red
1
red
3
green
2
green
4
yellow
3
yellow
5
Power consumption
<1W
white
4
white
6
Lamp
LED, red, green, yellow, white, blue
blue
5
blue
7
Illumination
very bright, visible angle over 180°
Enclosure material
thermoplastic
Connection
terminals 2.5 mm2, fine-stranded
Electrical life
Complete order no.
Lamp module without actuating element
07-3353-41
>105 running hours
Actuating element Standard
05-0003-001
Storage and transport temperature
-55 °C to +70 °C
Weight
approx. 110 g
Please enter code number.
Technical data subject to change without notice.
Mounting
locked, bayonet lock
Shock resistance
DIN EN 60068-2-27, 30 g 18 ms
28
BARTEC
03-0330-0670-10/2017-BCS-320187/1
Increased oil resistance 05-0003-001
0 00 00BN
