Ropex RES-408/400VAC Controller
Technische Datenblätter / Produktdokumentation
| Marke |  |
| Kategorie | Regler |
| Produktname | Ropex RES-408/400VAC Controller |
| Produktcode | Nicht angegeben |
Kontaktieren Sie uns! Innerhalb von 24 Geschäftsstunden (ohne Wochenenden und Feiertage) bestätigen wir Lagerstatus und voraussichtliche Lieferzeit.
Produktbeschreibung
Ropex-Produkte, einschließlich Ropex RES-408/400VAC Controller, werden über Parallelimportkanäle bezogen und zuverlässig an unsere Kunden in United States geliefert. Imtek Engineering bietet Original-Ropex-Teile zu wettbewerbsfähigen Preisen an. Auch wenn Ropex RES-408/400VAC Controller nicht auf unserer Website gelistet ist, können Sie jederzeit ein Preisangebot anfordern – unser Team meldet sich umgehend.
United States6
Technical data
Type of construction
Line voltage
Controller:
Housing for installation in the electrical cabinet Snaps onto a standard top hat rail (DIN TS35 rail, 35mm)
acc. to DIN EN 50022 Dimensions: 90 x 75mm; height: 135mm (incl. terminals)
Terminal:
Housing for installation in the electrical cabinet Dimensions (W x H): 96 x 48mm; depth: 55mm (excl. connector)
Controllers manufactured as of June 2006:
115VAC version: 110VAC -15%…120VAC +10% (equivalent to 94…132VAC) 230VAC version: 220VAC -15%…240VAC +10% (equivalent to 187…264VAC)
400VAC version: 380VAC -15%…415VAC +10% (equivalent to 323…456VAC) Controllers manufactured between January 2004 and May 2006:
115VAC version: 115VAC -15%…120VAC +10% (equivalent to 98…132VAC) 230VAC version: 230VAC -15%…240VAC +10% (equivalent to 196…264VAC)
400VAC version: 400VAC -15%…415VAC +10% (equivalent to 340…456VAC) Controllers manufactured up to December 2003:
115VAC, 230VAC or 400VAC, tolerance: +10% / -15% depending on device version ( section 14 "How to order" on page 61)
Line frequency
47…63Hz, automatic adjustment to frequencies in this range
Heatsealing band type and temperature range
Controllers manufactured as of June 2006:
The temperature range and temperature coefficient settings can also be specified
in the ROPEX visualization software ( section 11.19 "Diagnostic interface / visualization software (as of June 2006)" on page 51) in addition to using the rotary
coding switch (see below):
Temperature range:
200°C, 300°C, 400°C or 500°C Temperature coefficient: 400…4000ppm (variable setting range)
Five different ranges can be set on the controller with the rotary coding switch:
Temperature coefficient 1100ppm, 0…300°C (e.g. Alloy A20), default Temperature coefficient 780ppm, 0…300°C (e.g. Alloy L)
Temperature coefficient 1100ppm, 0…500°C (e.g. Alloy A20) Temperature coefficient 780ppm, 0…500°C (e.g. Alloy L)
Temperature coefficient 3500ppm, 0…300°C (e.g. LEX3500) Controllers manufactured up to May 2006:
Default value 300°C, Alloy A20 The temperature range and alloy can be selected with MOD 37.
Analog output (actual value) Terminals 17+18
0…10VDC, Imax = 5mA Equivalent to 0…300°C or 0…500°C Accuracy: ±1% plus 50mV
Digital logic levels Terminals 5+7
LOW (0V): 0…2VDC, electrically isolated
HIGH (24VDC): 12…30V DC (max. current input 6mA) Reverse polarity-protected
Page 12
RES-408
Version 1
