Desch Denox® HSE Series Motor Gearbox Unit

Desch

Product Code: Denox® HSE Series
Brand: Desch



GET OFFER: info@imtek.com.tr

Description for Desch Denox® HSE Series Motor Gearbox Unit

The drive units of the HSE/HS - series are used with single or multi-stage design as main spindle drives in the power range of 40-125 kW in machine tool applications. They are characterized by their extraordinary compactness. The hydraulic circuits and media ducts for cooling and lubrication are integrated in the transmission housing. This yields to an installation geometry without distorting elements for interlocking installation with defined interfaces in the RAM contour. Optionally tool spindles with HSK, ISO and other interface can be offered or fitted. Beside of the listed standard sizes, it is also possible to realise customized drive units up to 200 kW.Denox® HSEPower 40 - 80 kWNominal torque 1,250 - 5,000 Nm
