EKF CU8-RS232 ESD Protected RS-232 Rear-I/O Module
EKF
Product Code: EKF CU8-RS232 ESD Protected RS-232 Rear-I/O Module
Artikelnummer: CU8-RS232
Brand: EKF
GET OFFER: info@imtek.com.tr
Description for EKF CU8-RS232 ESD Protected RS-232 Rear-I/O Module
Technical Feature Summary CU8-RS232Form FactorRear-I/O Module (60x31mm2)FunctionPHY Transceiver RS-232E (EIA-232E, CCITT V.28)ChipADM211ERS-232 ConnectorPC compatible, connector D-Sub 9-pos. maleData Transfer Rate230kbpsESD/EMI Protection±15kV (Human Body Model MIL-STD-883B)±8kV (Contact Discharge IEC1000-4-2)±15kV (Air-Gap Discharge IEC1000-4-2)±2kV Fast Transient Burst Immunity (EFT IEC1000-4-4)10V/m EMI Immunity (IEC1000-4-3)Short Circuit ProtectionCurrent limited to ±20mA typ. per signal channelPower Requirements+5V 0.1A max.TemperatureHumidityOperating temperature -40..+85°CRelative humidity 5-90%, non-condensingRecommended Products For EKF
