EKF DU1-MUSTANG XMC Mezzanine Module Dual Isolated RS-485 Asynchronous Interfaces

EKF

Product Code: EKF DU1-MUSTANG XMC Mezzanine Module Dual Isolated RS-485 Asynchronous Interfaces
Artikelnummer: DU1-MUSTANG
Brand: EKF

GET OFFER: info@imtek.com.tr

Description for EKF DU1-MUSTANG XMC Mezzanine Module Dual Isolated RS-485 Asynchronous Interfaces

Form factor XMC single-width mezzanine card 139mm x 74mmStack height 10mm XMC to hostHost I/F Connector P15 XMC - PCI Express, single lane, single linkOption P15 connector according to XMC 2.0 (white housing)+3.3V operated (VPWR not in use)PCI Express® bridge to dual-port UARTPLX Oxford 950 UART w. 128-byte transmit/receive FIFOAsynchronous baud rates up to 15MbpsWindows® & Linux device driver support5kV rms isolation barrier RS-485/RS-422 transceivers (Analog Devices)Configurable as half or full duplex±15 kV ESD protection on RS-485 input/output pinsData rate 16 MbpsConnect up to 256 nodes on one bus (driver enable control via DTR)Open- and short-circuit, fail-safe receiver inputsHigh common-mode transient immunity >25 kV/µsThermal shutdown protectionTwo front bezel male 9-pin D-Sub connectorsRS-485 ports isolated against each other and board circuitry (limited to 250VAC by D-Sub connector characteristics)On-board DIP-switches for full/half-duplex setting, and line termination on/offLong Term AvailabilityCoating, Sealing, Underfilling on RequestRoHS compliant 2002/95/ECOperating temperature: 0°C ... +70°C (industrial temperature range on request)Storage temperature: -40°C ... +125°C, max. gradient 5°C/minHumidity 5% ... 95% non condensingAltitude -300m ... +3000mShock 15g 0.33ms, 6g 6msVibration 1g 5-2000HzMTBF 121.5 yearsEC Regulations EN55022, EN55024, EN60950-1 (UL60950-1/IEC60950-1) subject to technical changesOrdering InformationPlease refer to List 22 for popular DU1-MUSTANG SKUsDU1-MUSTANG • D-SUB Connectors Pin Assignment
