EKF DX1-LYNX XMC Mezzanine Module - SATA Storage Dual-Channel SATA2 Controller & 1.8-Inch microSATA Solid State Drive

EKF

Product Code: EKF DX1-LYNX XMC Mezzanine Module - SATA Storage Dual-Channel SATA2 Controller & 1.8-Inch microSATA Solid State Drive
Artikelnummer: DX1-LYNX
Brand: EKF

GET OFFER: info@imtek.com.tr

Description for EKF DX1-LYNX XMC Mezzanine Module - SATA Storage Dual-Channel SATA2 Controller & 1.8-Inch microSATA Solid State Drive

Form FactorXMC single-width mezzanine card 149mm x 74mmStack height 10mm XMC to hostHost I/FConnectorsP15 XMC - PCI Express, single lane, single linkOption XMC 2.0 connector P15 (white housing)P14 PMC (Option) - Rear I/O SATASATA ControllerJMB363 PCI Express to SATA controllerDual-channel SATA II 3GbpsOption RAID Level 0/1/10Serial ATA AHCI compliantSupports SATA II Gen1m and Gen2m (eSATA)Supports Native Command Queuing (NCQ)Drivers available at ftp://driver.jmicron.com.twSolid State DriveModule suitable for 1.8-inch Micro SATA SSD (alternatively hard disk drive), dimensions according to SFF-8144 (54mm x 78.5mm x 5mm)Variety of industrial grade Micro SATA SSD manufacturers, e.g. Intel, Micron, Samsung, SanDisk, STEC, Supertalent, 64GB or beyond, SLC or MLC available, high speed data transferSSD can be provided by EKF or by customerSingle- or dual-drive option (RAID option for dual-drive)SATA ConnectorsEach SATA channel can be individually assigned either to an on-board drive, to a front bezel eSATA receptacle, or to the rear I/O connector (these are permanent manufacturing options, consider before ordering)P1: 15-pos. Micro SATA connector, suitable for 1.8-inch top mount drive (side 1 - module component side), optionP2: 15-pos. Micro SATA connector, suitable for 1.8-inch bottom mount drive (side 2 - module back side), optionP3, P4: Front bezel eSATA receptacles channel 1 / 2, optionP14: PMC rear I/O connector, optionThermal ConditionsOperating temperature: 0°C ... +70°CStorage temperature: -40°C ... +85°C, max. gradient 5°C/minEnvironmental ConditionsHumidity 5% ... 95% non condensingAltitude -300m ... +3000mShock 15g 0.33ms, 6g 6msVibration 1g 5-2000HzMTBFtbd * 106h subject to technical changesDX1-LYNX Front Bezel
