Elma CompactPCI Packet Switching (PICMG 2.16) Image

Elma CompactPCI Packet Switching (PICMG 2.16)

Elma

Product Code: CompactPCI
Brand: Elma



GET OFFER: info@imtek.com.tr

Description for Elma CompactPCI Packet Switching (PICMG 2.16)

CompactPCI Packet Switching (PICMG 2.16 Rev.1.0) is an extension of the PICMG 2.x family of specifications that overlays a packet-based switching architecture on top of CompactPCI to create an Embedded System Area Network (ESAN). It supplements the robust, reliable and hot-swap capable CompactPCI architecture with the easily integrated, low-cost, high-performance and extensible Ethernet.Features CompactPCI with Packet Switching (PICMG 2.16)Compliant with: PICMG 2.0 R3.0 CPCI Core SpecificationPICMG 2.1 R2.0 Hot Swap SpecificationPICMG 2.9 R1.0 System Management SpecificationPICMG 2.16 R1.0 CPCI Packet Switching Backplane SpecificationcPCI System Slot left or right1 or 2 Fabric Slots right or left1000 Mbps differential pairs connected to node slots (P3)Shrouds: P3 to P510-layer controlled impedance strip-line designV(I/O) voltage configurable (connected by default to +5 V)Fastons for supplying HDD and fansHot swap capability
