Elma cPCISerial Test Extenders

Elma

Product Code: cPCISerial
Brand: Elma



GET OFFER: info@imtek.com.tr

Description for Elma cPCISerial Test Extenders

Request PricingThe CPCI-Serial Test Extenders provide the connections between the backplane and SBC or peripheral modules. These boards are designed to give users the flexibility to measure and test their SBC or peripheral modules with the system in work. Design fulfills the CompactPCI® Serial specification and maintains a good integrity of all high speed signals FeaturesEuropacard form factor in 3U height, compliant to CompactPCI Serial specification (PICMG CPCI-S.0.R2)Designed to connect SBC or peripheral module to a backplane system slotHigh-speed connectors supporting data transfer rates of up to 12 GbpsSerial Interfaces such as PCI Express Gen. 3, SATA Gen. 3, USB2.0 and USB3.0Six connectors on each side are assembled to provide all necessary connections between SBC or peripheral Board and backplaneFront panel with ejectors and EMC gasketsPower LED for +12V on the front panelTest points and disconnecting jumpers for +12V and Standby voltages
