Maximum Operating Pressure10,000 psi (700 bar)Pressure Rating 1st Stage1000 psi (70 bar)Pressure Rating 2nd Stage10,000 psi (700 bar)Cylinder CompatabilitySingle-actingReservoir Capacity347 in3 (5500 cm3)Reservoir Capacity1.5 gal (5500 cm3)Usable Oil Capacity1.5 gal (5,5 litres)Maximum Flow at Rated Pressure20 in3/min (0,27 l/min)Output Flow Rate 1st Stage150 in3/min (2,0 l/min)Output Flow Rate 2nd Stage20 in3/min (0,27 l/min)Motor Size0.5 hpMotor Hertz50/60 HzMotor Phases1 PhMotor Voltage208-240 VDuty CycleExtendedValve FunctionAdvance / RetractValve OperationManualValve Type3-way, 2-position, normally openValve ModelVMP 10000DPower SourceElectricMotor Electrical Specification230 V, 1 Ph, 50/60 HzCharger Voltage230 VACCurrent Draw6.75 ampsSound Level62 - 70 dBaRelief Valve Adjustment Range1,000 - 10,000 psi (70 - 700 bar)Weight53 lbs (24,0 kg)
