The EL2624 output terminal has four relays each of which has a single contact. The relay contact is suitable for use at up to 125 V AC or 30 V DC. The EtherCAT Terminal indicates its signal state by means of light emitting diodes. The EL2624 has potential-free contacts. The power contacts are looped through.
Technical dataEL2624 | ES2624Connection technologyrelay outputNumber of outputs4 x make contactsNominal voltage125 V AC/30 V DCLoad typeohmicDistributed clocks–Ohmic switching current0.5 A AC/2 A DC per channelInductive switching currentno dataMinimum permitted load10 µA at 10 mV DC with intact contact coatingCurrent consumption E-bustyp. 200 mAElectrical isolation500 V (E-bus/field potential)Current consumption power contacts–Bit width in the process image4 outputsOperating cycles mech. (min.)1 x 108Operating cycles electr. (min.)2 x 105 (1 A/30 V DC)Configurationno address or configuration settingWeightapprox. 50 gOperating/storage temperature0…+55 °C/-25…+85 °CRelative humidity95 %, no condensationVibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27EMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4Protect. class/installation pos.IP 20/variablePluggable wiringfor all ESxxxx terminalsApprovalsCE, UL
