The KL1312 digital input terminal acquires the binary control signals from the process level and transmits them, in an electrically isolated form, to the higher-level automation unit. The Bus Terminal contains two channels that indicate their signal state by means of light emitting diodes. The input signal corresponds to the standard EN 61131-2, type 2. This way, it is possible to connect 2-wire sensors.
Technical dataKL1312 | KS1312Connection technology4-wireSpecificationEN 61131-2, type 2Number of inputs2Nominal voltage24 V DC (-15 %/+20 %)“0” signal voltage-3…+5 V (EN 61131-2, type 2)“1” signal voltage11…30 V (EN 61131-2, type 2)Input filtertyp. 0.2 msInput currenttyp. 6 mA (EN 61131-2, type 2)Current consumption K-bustyp. 3 mAElectrical isolation500 V (K-bus/field potential)Bit width in the process image2 inputsConfigurationno address or configuration settingWeightapprox. 50 gOperating/storage temperature0…+55 °C/-25…+85 °CRelative humidity95 %, no condensationVibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27EMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4Protect. class/installation pos.IP 20/variablePluggable wiringfor all KSxxxx Bus TerminalsApprovals/markingsCE, UL, ATEXEx markingII 3 G Ex nA IIC T4 Gc
