The KL2652 output terminal has two relays, each featuring a change-over contact. The relay contact can be used universally for switching devices requiring mains power up to 230 V AC or 300 V DC. The KL2652 Bus Terminal is equipped with potential-free contacts. The signal state of the Bus Terminal is indicated via LEDs.
Technical dataKL2652 | KS2652Number of outputs2 x change-overNominal voltage230 V AC (max. switching voltage 250 V AC/300 V DC)Switching voltage max.250 V AC, 300 V DCLoad typeohmic, inductive, lamp loadMax. output current5 A per channelSwitching currentmax. 1 A AC/1 A DC at 40 V DC; max. 0.15 A at 300 V DC (UL: max. 230 V AC, 1 A)Switching current max.1 A AC/1 A DC at 40 V DC; 0.15 A at 300 V DC (UL: max. 230 V AC, 1 A)Minimum permitted load100 mA (12 V DC)Lamp test, electronic ballastmax. 6 A starting currentElectrical isolation1.5 kV (K-bus/field potential); 2.5 kV rated surge voltage, overvoltage category IIICurrent consumption power contacts–Current consumption K-bustyp. 90 mABit width in the process image2 outputsSwitching frequency max.6/min. (at rated load)Operating cycles mech. (min.)5 x 106Operating cycles electr. (min.)1 x 106 (1 A/250 V AC)Configurationno address or configuration settingSpecial featuresreverse switching realisableWeightapprox. 55 gOperating/storage temperature0…+55 °C/-25…+85 °CRelative humidity95 %, no condensationVibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27EMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4Protect. class/installation pos.IP 20/variablePluggable wiringfor all KSxxxx Bus TerminalsApprovalsCE, UL
