The KL9515 power supply terminal generates an output voltage of 15 V DC from the (24 V DC) input voltage, which can be accessed at the terminal. The following Bus Terminals are also supplied with this voltage via the power contacts. The power LEDs indicate the terminal’s operating state. The input voltage and the output voltage U0 are not electrically isolated.
Technical dataKL9515 | KS9515Input voltage24 V DC (-15 %/+20 %)Output voltage15 V DC ±1 %Output current0.5 ADiagnostics in the process image–Current consumption K-bus–Short-circuit-proofyesElectrical isolation–Residual ripple< 5 mVSpecial featuresstabilised output voltage, overcurrent LEDWeightapprox. 65 gOperating/storage temperature0…+55 °C/-25…+85 °CRelative humidity95 %, no condensationVibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27EMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4Protect. class/installation pos.IP 20/variablePluggable wiringfor all KSxxxx Bus TerminalsApprovalsCE, UL, Ex
