KL1382 | 2-channel digital input terminal thermistor
The digital KL1382 input terminal analyses the input signal of thermistor sensors with the aid of a current loop and a voltage < 5 V. The KL1382 is a monitoring device for the thermal machine protection of PTC sensors, suitable for the direct monitoring of motors, bearings and equipment. In the process image, the state of the sensor is indicated by one bit each. A further bit reports short-circuits or line interruptions. Red or green LEDs indicate the state of the two input bits.
Technical dataKL1382 | KS1382Connection technology2-wireSpecificationthermistor PTCNumber of inputs2Nominal voltage24 V (-15 %/+20 %)“0” signal voltage≤ 1.5 kΩ“1” signal voltage≥ 3 kΩSignal “0“ release≤ 1.5 kΩSignal “1“ excess temperature≥ 3 kΩSensor voltage≤ 5 VDiagnosticsopen-circuit monitoring > 8 kΩ, short-circuit diagnostic < 25 ΩInput filter30 msCurrent consumption K-bustyp. 60 mAElectrical isolation500 V (K-bus/field potential)Bit width in the process image4 inputsConfigurationno address or configuration settingSpecial featuresmonitoring device for thermal machine protectionWeightapprox. 55 gOperating/storage temperature-25…+60 °C/-40…+85 °CRelative humidity95 %, no condensationVibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27EMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4Protect. class/installation pos.IP 20/variablePluggable wiringfor all KSxxxx Bus TerminalsApprovalsCE, UL, Ex, GL
