NSD NDP-A211A1 External Display

3. SPECIFICATONS 3-1. General Specifications Item
Specifications NDP-A211A1 (standard type)
Model Power supply voltage Permissible power voltage range Power consumption
Insulation resistance Withstand voltage Vibration resistance Ambient operating temperature
Ambient operating humidity Ambient operating environment Ambient storage temperature
Grounding Construction Outside dimension (mm) Mass
NDP-A221A1 (compact type)
24VDC 21.6 to 30VDC 5W or less 20 MΩ or more between external DC power terminals and ground
(by 500 VDC insulation resistance tester) 500 VAC, 60Hz for 1 minute between external DC power terminal
and ground 20m/s2 10 to 500Hz, 10cycles of 5 minutes in 3 directions, conforms to JIS C 0040 standard
0 to +55°C (No freezing) 20 to 90 %RH (No condensation) Free from corrosive gases and excessive dust
-10 to +70°C Must be securely grounded (ground resistance of 100 Ω or less)
Panel mounting 110(W) x 110(H) x 46(D) 150(W) x 150(H) x 46(D) (Refer to dimensions for details.) (Refer to dimensions for details.)
Approx. 0.7kg Approx. 0.6kg
3-2. Performance Specifications Item
Specifications
Display items
Current position value, rotation speed Roulette display area: 9° Numeric display area: 1°
Current position value display unit Rotation speed display range
2500 spm (VS-5FD /5FX /5FXG /5ED /5EX /5EXR /5EXG) 4500 spm (VS-6E /7 /7R)
Rotation speed display sampling time
1s
Max. cable length
Max. 100 m *1
Note *1: If a cable between the external display unit and VARICAM is extended, a speed error will occur depending on
the rotation speed. For the speed error, refer to the following figures. (The value might be different by the
condition.)
