SICK 1111725 type: DBS60E-THFK01024 Incremental encoder
Fichas Técnicas / Documentación del Producto
- No hay documentación técnica disponible para este producto en este momento. Contáctenos para obtener más información.
| Marca |  |
| Categoría | Encoder |
| Nombre del producto | SICK 1111725 type: DBS60E-THFK01024 Incremental encoder |
| Código de producto | DBS60E-THFK01024 |
¡Ponte en contacto con nosotros! En 24 horas laborables (excepto fines de semana y festivos) confirmaremos el estado del inventario y el plazo estimado de entrega.
Descripción del producto
Los productos SICK, incluido SICK 1111725 type: DBS60E-THFK01024 Incremental encoder, se obtienen a través de canales de importación paralela y se entregan a nuestros clientes en United States con rapidez y fiabilidad. Imtek Engineering ofrece piezas originales SICK a precios competitivos. Aunque SICK 1111725 type: DBS60E-THFK01024 Incremental encoder no figure en nuestro sitio web, puede solicitar una cotización en cualquier momento y nuestro equipo le responderá en breve.
United States- PERFORMANCE
Pulses per revolution 1,024 Measuring step ≤ 90° electric/pulses per revolution Measuring step deviation ± 18° / pulses per revolution Error limits Measuring step deviation x 3 Duty cycle ≤ 0.5 ± 5 % Initialization time < 5 ms 1) - 1) Valid signals can be read once this time has elapsed.
- INTERFACES
Communication interface Incremental Communication Interface detail TTL 1) - 1) Output level depends on the supply voltage.
- ELECTRICAL DATA
Connection type Male connector, M12, 8-pin, radial Power consumption ≤ 0.5 W (without load) Supply voltage 4.5 ... 30 V Load current ≤ 30 mA, per channel Output frequency + 300 kHz 1) Reference signal, number 1 Reference signal, position 90°, electric, logically gated with A and B Reverse polarity protection ✔ Short-circuit protection of the outputs ✔ 2) MTTFd: mean time to dangerous failure 500 years (EN ISO 13849-1) 3) - 1) Up to 450 kHz on request.
- 2) Short-circuit opposite to another channel, US or GND permissable for maximum 30 s.
- 3) This product is a standard product and does not constitute a safety component as defined in the Machinery Directive. Calculation based on nominal load of components, average ambient temperature 40°C, frequency of use 8760 h/a. All electronic failures are considered hazardous. For more information, see document no. 8015532.
- MECHANICAL DATA
Mechanical design Through hollow shaft, Front clamp Shaft diameter 15 mm Flange type / stator coupling 2-sided stator coupling, slot, screw hole circle 63–83 mm Weight + 0.25 kg 1) Shaft material Stainless steel Flange material Aluminum Housing material Aluminum Start up torque + 0.5 Ncm (+20 °C) Operating torque 0.4 Ncm (+20 °C) Permissible shaft movement, axial static/dynamic ± 0.5 mm / ± 0.2 mm 2) Permissible shaft movement, radial static/dynamic ± 0.3 mm / ± 0.1 mm 2) Moment of inertia of the rotor 50 gcm² Bearing lifetime 3.6 x 109 revolutions Angular acceleration ≤ 500,000 rad/s² - 1) Based on an encoder with a male connector outlet or a cable with a male connector outlet.
- 2) Not apllicable for stator coupling type C and K.
- AMBIENT DATA
EMC According to EN 61000-6-2 and EN 61000-6-3 Enclosure rating IP65, housing side (according to IEC 60529) 1)
IP65, shaft side (according to IEC 60529)
Permissible relative humidity 90 % (condensation of the optical scanning not permitted) Operating temperature range –30 °C ... +100 °C, at maximum 3,000 pulses per revolution 2) Storage temperature range –40 °C ... +100 °C, without package Resistance to shocks 250 g, 3 ms (according to EN 60068-2-27) Resistance to vibration 30 g, 10 Hz ... 2,000 Hz (according to EN 60068-2-6) - 1) With mating connector fitted.
- 2) These values relate to all mechanical versions including recommended accessories unless otherwise noted.
- CLASSIFICATIONS
ECl@ss 5.0 27270501 ECl@ss 5.1.4 27270501 ECl@ss 6.0 27270590 ECl@ss 6.2 27270590 ECl@ss 7.0 27270501 ECl@ss 8.0 27270501 ECl@ss 8.1 27270501 ECl@ss 9.0 27270501 ETIM 5.0 EC001486 ETIM 6.0 EC001486 UNSPSC 16.0901 41112113
