FIP Italy DKOAC Series DN 15÷65 DIALOCK® 2-way Diaphragm Valve
FIP Italy
Product Code: DKOAC Series DN 15÷65
Brand: FIP Italy
GET OFFER: info@imtek.com.tr
Description for FIP Italy DKOAC Series DN 15÷65 DIALOCK® 2-way Diaphragm Valve
DIALOCK® diaphragm valve with flanged monolithic body, drilled ANSI B16.5 cl. 150 #FFDIALOCK® 2-WAY DIAPHRAGM VALVE• Connection system for solvent weld, threaded and flanged joints• Optimised fluid dynamic design: maximum output flow rate thanks to theoptimised efficiency of the fluid dynamics that characterise the new internalgeometry of the body• Internal components in metal, totally isolated from the fluid and externalenvironment• Modularity of the range: only 2 handwheel and 4 diaphragm and bonnetsizes for 7 different valve sizes• Non-rising handwheel that stays at the same height during rotation,equipped with a graduated optical indicator protected by a transparentPVC cap with seal O-Ring• Bonnet fastening screws in stainless steel protected against the externalenvironment by PE plugs. Absence of metal parts exposed to the externalenvironment to prevent any risk of corrosion• New flanged bodies: the new bodies, characterised by a monolithicflanged structure, are available in PVC-U, PVC-C, PP-H and PVDF. Thisdesign, free from body and flange joints, greatly reduces mechanical stressand increases system performance.• CDSA (Circular Diaphragm Sealing Angle) system that, thanks to theuniform distribution of shutter pressure on the diaphragm seal, offers thefollowing advantages:??reduction in the tightening torque of the screws fixing the actuator tothe valve body??reduced mechanical stress on all valve components (actuator, body anddiaphragm)??easy to clean valve interior??low risk of the accumulation of deposits, contamination or damage tothe diaphragm due to crystallisation??operating torque reduction EPDM code FKM code PTFE code DKOAC012E DKOAC012F DKOAC012P DKOAC034E DKOAC034F DKOAC034P DKOAC100E DKOAC100F DKOAC100P DKOAC114E DKOAC114F DKOAC114P DKOAC112E DKOAC112F DKOAC112P DKOAC200E DKOAC200F DKOAC200P DKOAC212E DKOAC212F DKOAC212PRecommended Products For FIP Italy
