FIP Italy LKDIC Series DN 10÷50 DUAL BLOCK® 3-way Ball Valve

FIP Italy

Product Code: LKDIC Series DN 10÷50
Brand: FIP Italy



GET OFFER: info@imtek.com.tr

Description for FIP Italy LKDIC Series DN 10÷50 DUAL BLOCK® 3-way Ball Valve

DUAL BLOCK® 3-way ball valve with metric plain socket ends for solvent welding, L bore.DUAL BLOCK® 3-WAY BALL VALVE• Connection system for solvent weld, threaded and threaded joints• Patented SEAT STOP® ball carrier system that lets you micro-adjust ballseats and minimise axial force effects• Easy radial disassembly allowing quick replacement of O-rings and ballseats without any need for tools• PN16 True Union valve body made for rigid PVC-C injection mouldingequipped with built-in bores for actuation. ISO 9393 compliant test requisites• Option of disassembling downstream pipes with the valve in the closedposition• High surface finish stem with double O-Ring and double connection keyto the ball, equipped with visual ball position indicator for correct handleinstallation• Carrier integrated in the body for valve anchoring• Possibility of installing pneumatic and/or electric actuators thanks to therobust integrated bracket for valve anchoring for easy and quick automationusing the Power Quick module (optional)• Valve material compatibility (PVC-C) and elastomer seal elements (EPDMor FKM), with water, drinking water and other food substances as percurrent regulations• Possibility to have handle with integrated LSQT limit micro switch, even asa retrofit in existing installations EPDM code FKM code LKDIC016E LKDIC016F LKDIC020E LKDIC020F LKDIC025E LKDIC025F LKDIC032E LKDIC032F LKDIC040E LKDIC040F LKDIC050E LKDIC050F LKDIC063E LKDIC063F
