Fortress Interlocks EN2T6EKL2ST401 Prohandle Actuator Safety Switch Interlock
Fortress Interlocks
Product Code: EN2T6EKL2ST401
Brand: Fortress Interlocks
GET OFFER: info@imtek.com.tr
Description for Fortress Interlocks EN2T6EKL2ST401 Prohandle Actuator Safety Switch Interlock
EN & EH PROHANDLEUsed in conjunction with the proAT Head.Particularly useful for applications using small radius hinged doors.Intuitive opening style.Zinc alloy casing.Built in lock-out facility to accommodate a maximum of 4 padlocks with up to 8mm diameter shackles.Mis-alignment +/- 12mm.Escape release option for use with non-locking system (proStop) or push IR only.On site handing change possible (refer to Installation Instructions).proE Extracted Key Lock Adaptor is used to add to an amGardpro unit, to include the provision of key control functionality. It can be used to provide an enhanced safety key function, where the door cannot be opened until the key has been removed from the lock. The releasing version of the extracted key adaptor is the type that MUST be used if used in conjunction with any type of internal release function (push IR) or all in one head module with IR Handle. This unit ensures that the door cannot be opened until thekey has been removed from the lock, and the machine/process cannot be restarted without returning the key(s).It can furthermore prevent personnel being accidentallylocked inside a guarded area. • Provides unique link to mGard range.• Only 1 Extracted key adaptor can be fitted in a configurationNAMEEK PROE - EXTRACTED KEY ADAPTORPART NO.EKRANGEHeavy Duty Guard Locking with PROFIsafe & CIP Safety - amGardproDepressing the plunger breaks the dual safety circuits to shut down the motive power to the machine and makes the monitoring circuit.• Ideal for quick access to machines with no or short run-down cycles• LED indicators for status identification• To be used with safety relay and/or safety PLC control systems• European, Canadian and North American ApprovalsNAMEST PROSTOP - NON SOLENOID SWITCH BODYPART NO.STRANGEHeavy Duty Guard Locking with PROFIsafe & CIP Safety - amGardproUsed in conjunction with the proAT Tongue Actuator.Ideal for fast, frequent access.4 position fixing at 90° increments allowing on site handing changeMisalignment tolerance of +/- 12mm.12mm Over travel allowance.Retention force 10,000N when top fixing is usedCan be fitted with lock-out devices for additional safety.Mounted upside down it is self cleaning, ideal for dusty environments.NAMET6, T7 & T8 PROAT HEAD MODULEPART NO.T6 T7 T8RANGEHeavy Duty Guard Locking with PROFIsafe & CIP Safety - amGardproRecommended Products For Fortress Interlocks
